INTRODUCTION The Arduino DMX shield is an add-on (or "shield") for the Arduino. It is an easy way to use the Arduino as a DMX-Master device, just by adding the DMX-shield on the top of the Arduino.   The following settings are configurable via the onboard jumpers: Send data via TX or Digital pin 4 Receive data via RX or Digital pin 3 Hardware slave mode or Software Controlled Slave/Master via Digital pin 2 (Required for RDM) Enable / Disable shield  In case you have the shield configured to use the RX and TX pins you have to disable the shield before you can upload your new sketch onto the Arduino board. This jumper allows you to disable the shield without disconnecting it from the Arduino board which saves time. SPECIFICATION Remote Device Management DMX Master DMX Slave SHIPPING LIST DMX shield       x1
